Quick Details

  • Type: servo motor drive
  • Control mode: speed/position/internal speed
  • Temperature: 0 to 50 C
  • Humidity: less than 90% no dewing
  • Certificate: CE/GB-T12688.2-2002
  • Rated Voltage: 220v
  • Application: cnc

Packaging & Delivery

Packaging Details 1)cartons for packing
2)based on your requirement.
3)offer label service
Delivery Time 7 working days after receiving the payment

 2500ppr incremental encoder  electric 400w ac servo motor and drive for cnc machine

The price is included a set of servo motor and drive.Should you want to have the seperated price,please kindly contact us!



Technical Data

power source



Single phase AC220V

input  strong current

Three phase AC220V



suitable environment

 temprature

 operating between 0 to55C

 humidity

below 90% RH no dewing

 vibration

Below 0.5G(4.9m/s2) no continue running

control mode

 position control

 speed control

 inner control

regenerative braking

  in sets



characteristic

speed frequency response

500HZ

speed undulation rate



Velocity modulation ratio

1:5000

Input pulse frequency

0-500KHZ



Input control

servo EN , Alarm Clr , deviation counter reset , instruction pulse prohibit, CCW driver prohibit , CW driver prohibit,  the second electrical gear ratio

 output control

Servo ready output, Servo alarming output,lacation ready output, speed arrival output.

Position control

 input way

Two-phase A/B orthogonality pulse,pulse+direction,CCW/CWpluse

electric gear ratio

1-32767

feedback pulse

Highest 10000 pulse/revolution

acceleration/deceleration function

Preference  1-10000ms

surveillance function

 rotating speed , introduction pulse accumulate ,motor torque ,  motor current, rotor's location, introduction, pulse frequency, operating statue , input and output's terminal signal  so on

Protection function

main power source being over press, owes press, over current, overload, unusual braking,unusual Encoder and so on.

 operation

six LED digital tubes    four keypads

suitable the load inertia

less than electrical machinery inertia five times
